Certificates
Features
- Fast & easy assembly
- Compatible with floor heating
- Impact resistant
- UV resistant
- Stratch resistant
- Eco-friendly
- Not affected by stains
- Easily cleaned
- Resistant to chair castor abrasion
- Fire resistant
- Wear layer
| Characteristics | Norm | Symbol | Requirement |
|---|---|---|---|
| Dimension | ASTM F2055 |  |
9″ x 60″ 228mm x 1524mm Length: 0/+0.3 Width: 0/+0.1 |
| Total Thickness | ASTM F387 |  |
8 mm -0.1/+0.13mm |
| Click systems | - |  |
Uniclic Patented |
| Beveled Edge | - |  |
Yes - Micro Bevel |
| Finish | - | Wood grain | |
| Thickness of Wear Layer | ASTM F410 | 20 Mil 0.5mm |
|
| Underlayment | - | 2.0 mm (EVA Padding) | |
| Net Weight | - | 4.4kgs/plank(±3%) 5 planks/box 21.5kgs/box (47.4 lbs/box) |
|
| Package | - | 1.667,87SQM | 4800 planks | 960 boxes | 20 pallets | 1 cont 20GP | |
| Dimensional Stability | ASTM F2199 | 0.02% | |
| Curling | ISO 23999 | 0.10mm | |
| Squareness (plank) | ASTM F2055 | 0.15mm | |
| Width Flatness | ISO 24337 | fw = 0.1% | |
| Length Flatness | ISO 24337 | fl = 0.15% | |
| Cupping Flatness | ISO 24337 | 0.1mm | |
| Openings / Assembling | ISO 24337 | 0.05mm | |
| Ledging | ISO 24337 | 0.1mm | |
| Abrasion Resistance | ASTM D4060-25 |  |
4.1mg |
| ASTM Specification Classification | ASTM F3261 | Class 1, Type B, Grade 1, Class B | |
| Resistance to Staining | ASTM F925 |  |
No visible staining, discoloration, or surface degradation |
| Furniture Leg | ASTM F2753 |  |
No visible damage |
| Castor Chair |  |
No visible damage after 25,000 cycles | |
| Heat stability (color change) | ASTM F1514 | ∆E ≤ 8.0 | |
| Light Stability (Color Change Test) | ASTM F1515 |  |
∆E ≤ 8.0 |
| Gloss Level | ASTM D523 | Ultra Matte <10 GU | |
| Locking Strength | ASTM F2823 | Longitudinal joint: 3.4 kN/m, Trans joint 3.6 kN/m |
|
| Impact Sound Reduction | ASTM E492-09 | IIC 72 (Sound Ratings were achieved in a lab environment. For accurate sound ratings, on-site testing must be done) | |
| STC Sound Testing | ASTM E90-09 | STC 68 (Sound Ratings were achieved in a lab environment. For accurate sound ratings, on-site testing must be done) | |
| IIC Sound Testing | ASTM E 989-18 | IIC 72 (Sound Ratings were achieved in a lab environment. For accurate sound ratings, on-site testing must be done) | |
| Static Electrical Loading | ASTM F150 |  |
≤ 2.0 kV (2000V) |
| Micro Scratch Resistance | EN 16094:2012, Procedure A&B |  |
MSR-A1, MSR-B |
| Strickeer Impacted by a Falling Weight | ASTM D5420-21 | 8.1J | |
| Surface treatment (UV) | - | 2-pass UV cured urethane | |
| Surface Integrity | ASTM F1914 | No visible changes or only minor indentation | |
| Residual Indentation | ASTM F1914 | 0.1mm | |
| Static Load (Residual Indentation) | ASTM F970 | 0.05mm | |
| Reaction to Fire | ASTM E648 |  |
Class I (≥ 0.45 W/cm²) |
| Formaldehyde | ASTM E1333 |  |
CARB P2 |
| Pentachlorophenol (PCP) | CP 491510-01 | PCP levels ≤ 5 ppm | |
| Thermal Resistance | ASTM C518 |  |
0.02 to 0.05 m²·K/W (or 0.1 to 0.3 ft²·h·°F/BTU) |
| Slip Resistance ( Slip Resistance for Coated Surfaces) | ASTM D2047 |  |
Dry Surface COF ≥ 0.50 Wet Surface COF ≥ 0.42 |
| Floor Heating System | Yes suitable, see separate installation instructions |  |
Max.27° C |
| FloorScore | Indoor Air Quality Certified to SCS-EC10.3-2014 v4.0 |  |
confirm |
